tensorflow 自定义指标 - MacroRecall & MacroF1

Tensorflow 自带的指标不够用，尤其是处理不平衡数据集时，macro recall 可以指示出不被 classes weight 所影响的平均recall。

定义

自定义指标 class 需要继承 tf.keras.metrics.Metric

解释一下其中的 function

reset_states 每个epoch结束后清零
update_state 在一个epoch中每个step update的方式
result 返回的值

我在 class 中维护了一张 confusion_matrix 叫做total_cm。因此能很方便的计算macro recall，macro f1 等数值。

通过confusion_matrix可以计算其他很多的数值，可以通过修改process_confusion_matrix 来实现

用法

下面定义了两个自定义指标 MacroRecall 和 MacroF1 ，使用的时候只要在model.compile时加进metrics即可。

class MacroRecall(tf.keras.metrics.Metric):
    def __init__(self, num_classes=2, **kwargs):
        super(MacroRecall,self).__init__(name='macro_recall',**kwargs) # handles base args (e.g., dtype)
        self.num_classes=num_classes
        self.total_cm = self.add_weight("total", shape=(num_classes,num_classes), initializer="zeros")

    def reset_states(self):
        for s in self.variables:
            s.assign(tf.zeros(shape=s.shape))

    def update_state(self, y_true, y_pred,sample_weight=None):
        self.total_cm.assign_add(self.confusion_matrix(y_true,y_pred))
        return self.total_cm

    def result(self):
        return self.process_confusion_matrix()

    def confusion_matrix(self,y_true, y_pred):
        """
        Make a confusion matrix
        """
        y_true=tf.argmax(y_true,1)
        y_pred=tf.argmax(y_pred,1)
        cm=tf.math.confusion_matrix(y_true,y_pred,dtype=tf.float32,num_classes=self.num_classes)
        return cm

    def process_confusion_matrix(self):
        cm=self.total_cm
        diag_part=tf.linalg.diag_part(cm)
        # precision=diag_part/(tf.reduce_sum(cm,0)+tf.constant(1e-15))
        recall=diag_part/(tf.reduce_sum(cm,1)+tf.constant(1e-15))
        # f1=2*precision*recall/(precision+recall+tf.constant(1e-15))
        return tf.reduce_sum(recall)/self.num_classes


class MacroF1(tf.keras.metrics.Metric):
    def __init__(self, num_classes=2, **kwargs):
        super(MacroF1,self).__init__(name='macro_f1',**kwargs) # handles base args (e.g., dtype)
        self.num_classes=num_classes
        self.total_cm = self.add_weight("total", shape=(num_classes,num_classes), initializer="zeros")

    def reset_states(self):
        for s in self.variables:
            s.assign(tf.zeros(shape=s.shape))

    def update_state(self, y_true, y_pred,sample_weight=None):
        self.total_cm.assign_add(self.confusion_matrix(y_true,y_pred))
        return self.total_cm

    def result(self):
        return self.process_confusion_matrix()

    def confusion_matrix(self,y_true, y_pred):
        """
        Make a confusion matrix
        """
        y_true=tf.argmax(y_true,1)
        y_pred=tf.argmax(y_pred,1)
        cm=tf.math.confusion_matrix(y_true,y_pred,dtype=tf.float32,num_classes=self.num_classes)
        return cm

    def process_confusion_matrix(self):
        cm=self.total_cm
        diag_part=tf.linalg.diag_part(cm)
        precision=diag_part/(tf.reduce_sum(cm,0)+tf.constant(1e-15))
        recall=diag_part/(tf.reduce_sum(cm,1)+tf.constant(1e-15))
        f1=2*precision*recall/(precision+recall+tf.constant(1e-15))
        return tf.reduce_sum(f1)/self.num_classes

# model
model.compile(metrics=['accuracy',MacroRecall(num_classes),MacroF1(num_classes)])
